AirMedia® Alıcı 3200 (AM‑3200‑WF‑I), modern dijital çalışma alanında güvenli kablosuz işbirliğine olanak tanır. Verimli bir toplantı ortamı oluşturmak için, Dağıtılması ve yönetilmesi kolay olan Alıcıyı konferans salonlarına, küçük odalara, dinlenme salonlarına, lobilere veya hemen hemen her alana kurun.
Öne Çıkan Özellikler
- Eksiksiz oda çözümü, kablolu bir HDMI® bağlantısı veya kablosuz bir AirMedia® bağlantısı kullanarak dizüstü bilgisayarlar, akıllı telefonlar, tablet cihazlar ve AirMedia Bağlantı Adaptörlerinden güvenli sunum sağlar
- HDMI® girişi, çift LAN, dengeli ses çıkışı ve RS‑232 ve IR aracılığıyla ekran kontrolü gibi entegrasyon dostu özellikler
- Akıllı ekran kontrolü, kişisel cihaz kontrolü, doluluk tespiti ve daha geniş bir bağlantılı ekosisteme entegrasyon yoluyla akıllı otomasyona olanak tanır
- Kurumsal düzeyde güvenlik ve içerik şifreleme, gizliliği korur ve BT politikalarıyla uyumluluğu sağlar
- Uzaktan provizyon ve yönetim için XiO Cloud® hizmet desteği
- Appspace® yazılımı ve diğer web tabanlı tabela sağlayıcılarını destekleyen yerleşik dijital tabela işlevselliği
- Kablosuz konferans ve sunum, oda içi ve uzaktaki katılımcılarla işbirliğine olanak tanır
Teknik Özellikler
| Ethernet | 100/1000 Mbps, auto-switching, autonegotiating, autodiscovery, full/half duplex, TCP/IP, UDP/IP, DHCP, SSL, TLS 5 , SSH, SFTP (SSH File Transfer Protocol), IEEE 802.1x, Active Directory authentication, HTTPS web browser setup and XiO Cloud service, 802.3at compliant |
|---|---|
| Wi-Fi | Dual-band 802.11a/b/g/n/ac/ax (2.4 GHz & 5 GHz); Up to 100 ft (30 m) range at 80 Mbps, subject to site‑specific conditions |
| Bluetooth® Communications | Bluetooth version 5.0 |
| AirMedia | Via Ethernet: IPv4, mDNS, TLS, AES 1 ; Via wireless access point: IEEE 802.11/b/g/n/ac/ax, 2.4 GHz or 5 GHz |
| USB Host | USB 2.0 for connecting a USB conferencing peripheral; USB 3.0 for connecting a USB conferencing peripheral |
| USB Device | USB 3.0 for computer console (installer setup and firmware update) |
| RS-232 | 2-way display device control up to 115.2k baud with hardware and software handshaking |
| IR/Serial | 1-way display device control via infrared up to 1.1 MHz or serial TTL/RS-232 (0-5V) up to 19.2k baud |
| HDMI Input | HDCP 1.4, EDID; Supports management of HDCP and EDID |
| HDMI Output | HDCP 2.2, EDID, CEC; Supports management of HDCP and EDID |
| Input Signal Types | AirMedia, HDMI (Dual-Mode DisplayPort™ compatible 2 ) |
| Maximum Input Resolutions | HDMI Input: 1920×1080@60Hz (HD 1080p60); AirMedia presentation: 1920×1080@30Hz (1080p30); AirMedia Connect Adapter: 3840×2160@30Hz (4K30) NOTES: Other input resolutions are supported at pixel clock rates up to 148 MHz; interlaced video is not supported. All video inputs will be scaled to the selected HDMI output resolution. |
| Output Signal Types | HDMI (DVI compatible 2 ) |
| HDMI Output Resolutions | 1280×720@50Hz (720p50), 1280×720@60Hz (720p60), 1280×800@60Hz, 6 1366×768@60Hz, 6 1440×900@60Hz, 6 1600×900@60Hz, 6 1600×1200@60Hz, 1680×1050@60Hz, 6 1920×1080@50Hz (1080p50), 1920×1080@60Hz (1080p60), 3840×2160@30Hz (2160p30), 3840×2160@50Hz (2160p50), 3840×2160@60Hz (2160p60) NOTE: All video inputs will be scaled to the selected HDMI output resolution. |
| Background & Logo File Support | JPEG, PNG |
| Output Signal Type | HDMI |
| Input/Output Format | 2 channel LPCM |
| OS Support | Apple® iOS®, Android™, Windows 10, Windows 11, macOS®, Chrome OS™ |
| Video Frame Rate | Up to 30 fps, audio supported |
| Output Resolutions | 640×480@60Hz, 800×600@60Hz, 1024×768@60Hz, 1280×720@50Hz (720p50), 1280×720@60Hz (720p60), 1280×800@60Hz, 1366×768@60Hz, 1440×900@60Hz, 1600×900@60Hz, 1600×1200@60Hz, 1680×1050@60Hz, 1920×1080@50Hz (1080p50), 1920×1080@60Hz (1080p60) NOTE: All video inputs will be scaled to the selected HDMI output resolution. |
| Bitrate Peak | 0.25 to 8.5 Mbps, variable depending on content complexity |
| Bitrate Average | 1.4 Mbps typical NOTES: The bitrate for Apple native mirroring may deviate from above depending on the OS version and content. The AirMedia Extension for the Google Chrome browser relies on web technologies for screen sharing that are built-in to the web browser. Performance variations with motion video (quality and frame rate) may occur based upon the encoding capabilities of the Chrome OS device and the nature of the content being displayed (i.e., high-motion video). |
| Audio Format | Stereo |
| OS Support (AirMedia Application) | Windows 10, Windows 11 |
| OS Support (AirMedia Connect Adaptor) | Windows 10, Windows 11, macOS 11 or later |
| Supported Conferencing Services | Microsoft Teams software; Zoom software |
| Supported Conferencing Peripherals | For a list of supported conferencing peripherals, refer to OLH 1001764 . |
| ANT‑A & ANT‑B | (2) SMA connectors for external Wi‑Fi antennas; Wi‑Fi antennas included with 6.56 ft (2 m) cables |
| IR | (1) 2-pin 3.5 mm detachable terminal block; IR/Serial output port for display device control; IR output up to 1.1 MHz; 1-way serial TTL/RS-232 (0-5V) up to 19200 baud |
| COM | (1) 5-pin 3.5 mm detachable terminal block; Bidirectional RS-232 port for display device control; Up to 115.2k baud, hardware and software handshaking support |
| AUDIO OUT | (1) 5-pin 3.5 mm detachable terminal block; Balanced/unbalanced stereo line-level audio output; Maximum Output Level: 4 Vrms balanced, 2 Vrms unbalanced; Output Impedance: 200 ohms balanced, 100 ohms unbalanced |
| microSD | (1) microSD slot |
| HDMI INPUT | (1) HDMI Type A connector; HDMI digital video/audio input; (DVI & Dual-Mode DisplayPort compatible 2 ) |
| HDMI OUTPUT | (1) HDMI Type A connector; HDMI digital video/audio output (DVI compatible 2 ) |
| USB | (2) USB Type A connectors; USB 2.0 host port for USB conferencing peripheral; USB 3.0 host port for USB conferencing peripheral; (1) USB Type B connector; USB 3.0 device port for computer console |
| LAN PoE+ | (2) LEDs, green LED indicates Ethernet link status, amber LED indicates Ethernet activity |
| LAN AUX | (2) LEDs, green LED indicates Ethernet link status, amber LED indicates Ethernet activity |
| 24VDC 1.25A | (1) 2.1 x 5.5 mm DC power connector; 24VDC power input; PW‑2412WU power pack sold separately |
| PWR | (1) Green LED, indicates operating power supplied via the local power pack or PoE+ |
| RESET | (1) Recessed push button for hardware reset |
| SETUP | (1) Recessed push button for onscreen IP address display and for pairing the device to an AM‑TX3‑100; (1) Red/White LED, indicates pairing status |
| ONLINE | (1) Green LED, indicates control system connection |
| HDMI IN/OUT | (2) Green LEDs, indicate HDMI signal presence at the HDMI input/output |
| Power over Ethernet | IEEE 802.3at Class 4 Powered Device |
| Power Pack (sold separately) | Input: 100-240VAC, 50/60 Hz; Output: 1.25A @ 24VDC; Model: PW‑2412WU |
| Power Consumption | 14 W (typical) |
| Temperature | 32° to 104°F (-0° to 40° C) |
| Humidity | 10% to 90% RH (non‑condensing) |
| Heat Dissipation | 47.8 BTU/hr |
| Chassis | Metal, black finish, with (2) integral mounting flanges, vented sides |
| Mounting | Freestanding, surface mount, or attach to a single rack rail |
| Height | 1.26 in. (33 mm) |
| Width | 7.40 in. (188 mm) |
| Depth | 6.93 in. (177 mm) |
Kullanım Alanları
- Kurumsal ve ticari projelerde receiver çözümü
- Toplantı odaları, akıllı binalar ve otomasyon sistemlerine entegrasyon
- Profesyonel kurulum ve merkezi yönetim
Sıkça Sorulan Sorular
Crestron AM-3200-WF-I Türkiye’de satılıyor mu?
Evet. Avelkon, Crestron Türkiye yetkili distribütörüdür. Stok, fiyat ve proje teklifi için bizimle iletişime geçebilirsiniz.
Teknik destek ve kurulum sağlanıyor mu?
Evet, yetkili distribütör olarak ürün seçimi, kurulum ve satış sonrası destek sunuyoruz.
