Bir CATx kablosu üzerinden HDMI® veya USB-C® DisplayPort™ sinyalinin ve USB 2.0 sinyallerinin noktadan noktaya genişletilmesini sağlamak için DM® Essentials HD-RXU-4KZ Serisi alıcıyla birlikte çalışabilirlik. 4K60 4:4:4 videoyu, HDR10+ ve HDCP 2.3'ü destekler. Otomatik geçiş özelliğine sahip bir HDMI girişi ve bir USB-C DisplayPort girişi sağlar. USB-C DisplayPort girişi tarafından sağlanan şarj özelliği.
Teknik Özellikler
| Input Signal Types | HDMI, DisplayPort over USB-C (DisplayPort Alt Mode) |
|---|---|
| Output Signal Type | DM Essentials |
| Copy Protection | HDCP 2.3 |
| Resolutions | Common resolutions are listed in the following table. |
| Digital Formats | Dolby Digital®, Dolby Digital EX, Dolby Digital Plus, Dolby® TrueHD, Dolby Atmos®, DTS®, DTS ES, DTS 96/24, DTS HD® High Res, DTS-HD Master Audio, DTS:X®, LPCM up to 8 channels |
| HDMI | HDCP 2.3, EDID, CEC |
| USB‑C | HDCP 2.3, EDID, CEC; USB 2.0 up to 300 Mbps |
| USB | USB signal extension via USB 2.0 host and device ports |
| DM Essentials | HDCP 2.3, EDID; USB 2.0 up to 300 Mbps |
| Ethernet | 100/1000 Mbps, auto-switching, auto-negotiating, auto-discovery, full/half duplex, DHCP, Web browser setup and control, Crestron control system integration, IEEE 802.1X, Secure CIP, Authentication, SSH/SSL, TLS |
| SERVICE | (1) USB 2.0 Type-A connector, female; Used for firmware loading and configuration management; Can also provide up to 5V 500 mA power to a USB powered device |
| 24V 4.5A | (1) 2.1 x 5.5 mm DC power connector; 24VDC power input; PW-2475DU power pack included 4 |
| 60W USB, INPUT 1 | (1) USB Type-C® connector, female; Digital video/audio input using DisplayPort Alt Mode; USB 2.0 data support; Can also charge connected AV source with up to 60W of power 5 |
| HDMI, INPUT 2 | (1) HDMI Type A connector, female; HDMI digital video/audio input; DVI and Dual-Mode DisplayPort interface compatible 6 |
| DEVICE, INPUT 2 | (1) USB Type‑C® connector, female; USB 2.0 device port associated with HDMI input for AV sources that require USB 2.0 support; USB signal extender port for connection to a computer or other USB 2.0 host 3 |
| HOST | (2) USB Type-A connectors, female; USB 2.0 host ports; USB signal extender ports for connection to USB mice, keyboards, or other USB 2.0 devices; 3 Available Power: 500 mA @ 5VDC per port |
| DM OUT | (2) LEDs on RJ‑45 connector. Green indicates that a DM Essentials link is established; Flashing amber indicates non‑HDCP video, and solid amber indicates HDCP video |
| LAN | (2) LEDs on RJ‑45 connector; Green indicates that a 100 Mbps link is established; Solid amber indicates that a 1000 Mbps link is established; Flashing amber indicates 1000 Mbps Ethernet activity. |
| Ground | (1) Chassis ground lug |
| PWR | (1) LED, indicates that power is being applied to the device. Amber indicates that the device is booting. Green indicates that the device is operational. |
| AUTO | (1) Push button for enabling or disabling automatic switching of inputs; (1) LED, green indicates that automatic switching of inputs is enabled |
| SETUP | (1) Push button for Ethernet setup; (1) LED, red indicates that the SETUP push button is pressed |
| INPUT 1 | (1) Push button for manual selection of USB-C DisplayPort input; (1) LED, green indicates that the USB-C DisplayPort input is routed to an output, and amber indicates that a source is detected but is not routed to an output |
| INPUT 2 | (1) Push button for manual selection of HDMI input; (1) LED, green indicates that the HDMI input is routed to an output, and amber indicates that a source is detected but is not routed to an output |
| Power Pack (Included) | Input: 100-240VAC Output: 24VDC 7.5A Model: PW-2475DU 4 |
| Temperature | 32° to 104°F (0° to 40°C) |
| Humidity | 20% to 90% RH (non-condensing) |
| Chassis | Metal, black finish, vented top, front, rear, and sides, 2 mounting brackets included |
| Mounting | Freestanding, surface mountable, or attachment to a single rack rail |
| Height | 1.20 in. (30 mm) |
| Width | 8.52 in. (216 mm) |
| Depth | 6.48 in. (165 mm) |
| DM-CBL-ULTRA DM® Ultra Cable | DM-CBL-8G DM 8G® Cable or CAT5e (UTP) or Higher |
Kullanım Alanları
- Kurumsal ve ticari projelerde transmitter w switching çözümü
- Toplantı odaları, akıllı binalar ve otomasyon sistemlerine entegrasyon
- Profesyonel kurulum ve merkezi yönetim
