Profesyonel olarak kurulmuş AV ve BT sistemleri için dikey rafa monte edilebilir 12A, 120V AC güç kontrol cihazı, klima ve aşırı gerilim koruyucu. PC-350V-18, raf çerçevesine monte edilmek üzere tasarlanmıştır, dolayısıyla rafta yer kaplamaz (Sıfır RU).
Teknik Özellikler
| Maximum Output Current, Total | 12A @ 120VAC |
|---|---|
| Maximum Output Current, Per Outlet | 12A @ 120VAC (subject to a maximum total output current of 12A for all outlets combined) |
| Filtration (Outlet 7-18) | -1.9 dB @ 100 kHz, -25 dB @ 300 kHz, -39 dB @ 500 kHz with 50 Ohm load |
| Surge Protection Modes | Line-Ground, Line-Neutral, Neutral-Ground |
| Surge Protection Shutoff | Shuts off outlets if surge protection is compromised |
| Joule Rating | 3640 Joules |
| Clamping Voltage | 600V |
| Clamping Time | 1 ns |
| Wiring Fault Detection | Shuts off outlets if the following wiring faults are detected at the input: Reversed polarity Missing ground wire |
| Voltage Sensing Range | 90 to 145V rms ±1%, measured at input |
| Current Sensing Range | 0.1 to 12A rms ±1% when load > 1A, measured per outlet |
| Under Voltage Cutoff | Adjustable 90 to 100V, shuts off outlets if input drops below set value |
| Over Voltage Cutoff | Adjustable 130 to 145V, shuts off rear outlets if input exceeds set value |
| Cycle Delay Adjustment | 5 to 300 seconds, adjustable per outlet |
| Startup Delay Adjustment | 1 to 10 seconds, adjustable per outlet |
| Line Power | 12A @ 120VAC, 60 Hz |
| Ethernet | 10/100 Mbps, auto-switching, auto-negotiating, auto-discovery, full/half duplex, TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SNMP, web server, web UI setup and control, Crestron control system integration, XiO Cloud monitoring |
| 120V~ 12A 60Hz | Detachable 9.8 ft (3 m) grounded AC power cord with NEMA 5-15P plug, line power input |
| OUTLET 1 -18 | (18) NEMA 5-15R AC power outlets; Individually-switched 120VAC power outlets; Adjustable power cycle delay per outlet; Adjustable startup delay per outlet; Remote switchable per outlet |
| TEMP | (1) 2-pin 3.5 mm detachable terminal block; Connection for external temperature sensor (not included) |
| LAN | (2) LEDs, green LED indicates Ethernet link status, amber LED indicates Ethernet activity |
| PWR | (1) Bi-color green/amber LED, indicates line power is present and: illuminates amber while booting illuminates green when the device is operating normally turns amber if the outlets have been shut off due to a fault condition blinks in amber during the factory reset process blinks in green when the "Identify" search process is initiated for the unit in the Crestron Home app |
| FAULT | (1) Red LED, indicates any of the following fault conditions: 2 surge protection is compromised line and neutral are reversed no ground is detected |
| PROTECT | (1) Green LED, indicates surge protection is fully functional |
| SHUTDOWN | (1) Amber LED, indicates power to outlets is shut off due to any of the of the following fault conditions: overvoltage undervoltage overcurrent line input miswire missing ground compromised surge protection fault condition |
| HW-R | (1) Recessed pushbutton; Initiates hardware reset, factory restore, DHCP reset, and power cycle of all outlets |
| THERMAL BREAKER | (1) Disconnects power to all outlets in case of an overload condition, press to reset after overload condition is resolved |
| Per Outlet Indicator | (1) Green LED: Illuminates when outlet is turned on blinks when the "Identify" search process is initiated for the outlet in the Crestron Home app |
| Temperature | 32° to 104°F (0° to 40°C) |
| Humidity | 10% to 90% RH (non-condensing) |
| Chassis | Metal, black finish |
| Mounting | 0 RU vertically rack-mounted (mounting brackets included) |
| Height | 48.10 in. (1221 mm) |
| Width | 1.73 in. (44 mm) |
| Depth | 2.60 in. (66 mm) |
Kullanım Alanları
- Kurumsal ve ticari projelerde power conditioners çözümü
- Toplantı odaları, akıllı binalar ve otomasyon sistemlerine entegrasyon
- Profesyonel kurulum ve merkezi yönetim
Sıkça Sorulan Sorular
Crestron PC-350V-18 Türkiye’de satılıyor mu?
Evet. Avelkon, Crestron Türkiye yetkili distribütörüdür. Stok, fiyat ve proje teklifi için bizimle iletişime geçebilirsiniz.
Teknik destek ve kurulum sağlanıyor mu?
Evet, yetkili distribütör olarak ürün seçimi, kurulum ve satış sonrası destek sunuyoruz.
Avelkon, Crestron Türkiye yetkili distribütörüdür. Fiyat ve proje teklifi için iletişime geçin.
