4 kanal ileri veya geri faz karartma Otomatik yük algılama 120 ila 240 Volt 50/60 Hz çalışma Hangi Crestron aydınlatma cihazlarının test edildiğini ve üçüncü taraf aydınlatma armatürleriyle uyumlu olduğunu öğrenmek için Crestron® Aydınlatma Armatür Uyumluluğu sayfasını ziyaret edin.
Teknik Özellikler
| Line Power | 120 – 240VAC, 50/60Hz |
|---|---|
| Input Channels | 1 |
| Dimmer Channels | 4 |
| Maximum Per Channel | 5A @ 120 to 240VAC, 50/60 Hz; 600 W @ 120VAC; 1150 W @ 230VAC; 1200 W @ 240VAC |
| Module Total | 10A @ 120 to 240VAC, 50/60 Hz; 1200 W @ 120VAC; 2300 W @ 230VAC; 2400 W @ 240VAC |
| Load Types | Forward Phase (leading edge) or Reverse Phase (trailing edge) Electronic Low Voltage, Incandescent, Neon/Cold Cathode, Magnetic Low Voltage, Dimmable 2-Wire Fluorescent, and Non-Dim Lighting |
| Minimum Load | 15 W per channel for Incandescent loads; 50 W per channel for Magnetic Low Voltage loads with Halogen or LED Lamps; 50 W for AC Dimmable LED loads operated in Auto/Forward-Phase Mode; 15 W for AC Dimmable LED loads operated in Reverse-Phase Mode |
| Cresnet | Cresnet secondary mode |
| NET | (1) Yellow LED; Indicates communication with the control processor |
| OVERRIDE | (2) 2-pin 3.5 mm detachable terminal blocks, paralleled; Sensing input for external low-voltage contact closure; Activates override mode when a closure is present; Minimum Closure Rating: 10mA (per module) at 24V |
| LIVE | (2) Captive screw terminals, brown; Line power connections; Accept up to 12 AWG (2.5 mm²) wires |
| NEUTRAL | (5) Captive screw terminals, blue; Neutral connections; Accept up to 12 AWG (2.5 mm²) wires |
| DIMMED LIVE 1 – 4 | (4) Captive screw terminals, red; Dimmer channel outputs 1 – 4; Accept up to 12 AWG (2.5 mm²) wires |
| Ground | (5) Captive screw terminals, green; Ground connections; Accept up to 12 AWG (2.5 mm²) wires |
| NET ID | (2) 7-Segment green LED digits and (2) miniature pushbuttons; For setting Cresnet ID; digits also display output levels and protection/error codes |
| SETUP | (1) Red LED and (1) recessed miniature pushbutton; For enabling setup mode and touch-settable ID |
| OVR | (1) Red LED and (1) miniature pushbutton; For enabling override mode and saving override presets |
| PWR | (1) Green LED; Lights to indicate AC line power is connected to either LIVE terminal, flashes when only powered by Cresnet |
| RESET | (1) Recessed miniature pushbutton; Resets internal processor |
| FWD 1 – 4 | (4) Red LEDs; Lights when a corresponding channel is operating in forward-phase mode |
| REV 1 – 4 | (4) Red LEDs; Lights when a corresponding channel is operating in reverse-phase mode |
| AUTO 1 – 4 | (4) Red LEDs; Lights when a corresponding channel is set to auto-detect the load type |
| NON-DIM 1‑4 | (4) Red LEDs; Lights when a corresponding channel is operating in non-dim mode |
| Channel Mode Select 1‑4 | (4) Recessed miniature pushbuttons; Used to select each channel’s operating mode |
| LOADS 1 – 4 | (4) Red LEDs and (4) miniature pushbuttons; Status indication and local control of each channel |
| Temperature | 32° to 104°F (0° to 40°C) |
| Humidity | 10% to 90% RH (noncondensing) |
| Heat Dissipation | 60 BTU/hr @ 240V with 2 channels at 5A 50 BTU/hr @ 120V with 2 channels at 5A |
| Enclosure | Aluminum with polycarbonate label overlay |
| Mounting | 35 mm DIN EN 60715 rail mount, DIN 43880 form factor for enclosures with 45 mm front panel cutout, occupies 12 DIN module spaces (216 mm) Sufficient ventilation is required to maintain an ambient temperature not exceeding 104°F (40°C), the unit dissipates significant heat when fully loaded; Maintain 4 in. (102 mm) spacing (minimum) or 6 in. (153 mm) spacing (recommended) above and below for proper ventilation and heat dissipation |
| Height | 3.71 in (95 mm) |
| Width | 8.48 in (216 mm) |
| Depth | 2.35 in (60 mm) |
Kullanım Alanları
- Kurumsal ve ticari projelerde din modules çözümü
- Toplantı odaları, akıllı binalar ve otomasyon sistemlerine entegrasyon
- Profesyonel kurulum ve merkezi yönetim
Sıkça Sorulan Sorular
Crestron DIN-1DIMU4 Türkiye’de satılıyor mu?
Evet. Avelkon, Crestron Türkiye yetkili distribütörüdür. Stok, fiyat ve proje teklifi için bizimle iletişime geçebilirsiniz.
Teknik destek ve kurulum sağlanıyor mu?
Evet, yetkili distribütör olarak ürün seçimi, kurulum ve satış sonrası destek sunuyoruz.
Avelkon, Crestron Türkiye yetkili distribütörüdür. Fiyat ve proje teklifi için iletişime geçin.
